Solenoid Valve | SUS 6-10 (2/2 WAY ~ SS BODY) | UNI-D

Solenoid Valve-Normally Closed Type

Product ID: SUS-6~10



PRODUCT DESCRIPTION

.SUS series is direct-acting, conductive, and normally closed (NC) 2/2 way

solenoid valve.

.Able to be operated directly without pressure

.Availability of fluid type:water, air, steam, light oil, gas, vacuum

.Acceptable for customization Viton (130℃) , Silicone (130℃) and EPDM (130℃)

Categories: ,

CAUTIONS:

.Before pipelining,the pipe line must be very clean without any contaminants or any other things not ought to be existed.

.To prolong the life time of the product, Y-line filter should be installed in the front end of solenoid valve.

.The temperature of steam should not over 185℃

.AC voltage tolerance:±10%;DC voltage tolerance:±1%

.It should be installed horizontally;vertical installation is not advisable.

Not Suitalbe For Fluid As Below:

.Liquid status when it is high temperature;solid status when it is cool.

.Corrosive fluid

.Viscosity over 50cst
