PRODUCT DESCRIPTION
．US series is multiplex, pilot operated piston, conductive and normally closed
(NC) 2/2 way solenoid valve.
．Availability of fluid type：steam, heavy oil
CAUTIONS：
．Minimum pressure to open：over 0.5~1kgf-c㎡
．Before pipelining, the pipe line must be very clean without any contaminants or any other things not ought to be existed.
．To prolong the life time of the product, Y-line filter should be installed in the front end of solenoid valve.
．AC voltage tolerance：±10%；DC voltage tolerance：±1%
．It should be installed horizontally；vertical installation is not advisable.
Not Suitalbe For Fluid As Below：
．Liquid status when it is high temperature；solid status when it is cool.
．Corrosive fluid
．Viscosity over 20cst
